A Developer’s Guide to Kubernetes Components

Kubernetes is the backbone of modern cloud-native applications. It simplifies deploying, scaling, and managing containerized workloads. But for developers, understanding its core concepts—like Pods, Deployments, and Services—is essential to building scalable and resilient apps.

In this guide, you learn about Kubernetes components from a developer’s point of view, complete with real-life use cases and visual diagrams.

Understanding Kubernetes Objects

Kubernetes uses a declarative object model. Each object’s spec defines the desired state. The status reflects the current state. Common fields are:

• apiVersion: API version (e.g., v1)
• kind: Object type (e.g., Pod, Service)
• metadata: Name, namespace, labels
• spec: Desired configuration
• status: System-managed status

For certain objects like Secrets and ConfigMaps, data and stringData fields are used to store key-value pairs.​Kubernetes API Server accepts object definitions in a JSON format, most often such definition manifests in a YAML format which is converted by kubectl in a JSON payload and sent to the API Server.

source <(minikube completion bash)

Nodes

A node is a physical or virtual machine in a Kubernetes cluster. Each node runs the following:

• kubelet: Ensures containers in a Pod are running.
• kube-proxy: Manages network rules for communication.
• Container runtime: Runs containers (e.g., Docker, containerd).

In a cloud-native e-commerce app, each node could run pods handling different services—payments, inventory, or recommendations.

There are two types of nodes:

• Control plane nodes: Manage the cluster. They run the API server, scheduler, controller manager, and etcd.
• Worker nodes: Run application workloads.

Namespaces

Namespaces partition cluster resources and isolate workloads. They allow teams to share a cluster without interfering with each other.

Default namespaces:

• default: For user-defined resources.
• kube-system: For system-level components.
• kube-public: Readable by all users.
• kube-node-lease: Used for node heartbeats.

If multiple users and teams use the same Kubernetes cluster you can partition the cluster into virtual sub-clusters using Namespaces. The names of the resources/objects created inside a Namespace are unique, but not across Namespaces in the cluster.

To list all namespaces:

kubectl get namespaces

To create a namespace:

kubectl create namespace <namespace-name>

Namespaces support:

• Unique resource names within each namespace
• Resource isolation by team, project, or environment
• Resource quotas and limits

A good practice, however, is to create additional Namespaces, as desired, to virtualize the cluster and isolate users, developer teams, apps, or tiers.

Pods

A Pod is the smallest deployable unit in Kubernetes. It can contain one or more containers that share:

• The same network namespace
• Storage volumes

Pods are ephemeral and typically managed by higher-level objects like Deployments.

Example, nginx-pod.yaml:

apiVersion: v1
kind: Pod
metadata:
  name: nginx-pod
spec:
  containers:
  - name: nginx
    image: nginx:1.22.1
    ports:
    - containerPort: 80

Apply the manifest:

kubectl apply -f nginx-pod.yaml

Generate the manifest without creating the Pod:

kubectl run nginx-pod --image=nginx:1.22.1

Labels and Selectors

Labels are key-value pairs used to organize, select, and manage Kubernetes objects. They are used by controllers and services to organize and manage resources, hence many objects can have the same Label(s).

Label Selectors:

• Equality-based: Select resources matching specific key-value pairs.​
  • kubectl get pods -l env=dev
• Set-based: Select resources matching a set of values.​
  • kubectl get pods -l 'env in (dev, qa)'

Use labels to group resources logically (e.g., by environment, app version).

ReplicaSets

A ReplicaSet ensures a specific number of identical Pods are always running.

Key features:

• Self-healing: Replaces failed Pods
• Scalable: Supports manual and automated scaling
• Uses label selectors to identify Pods

For example, consider a ReplicaSet with a replica count set to 3 for a specific Pod template. Pod-1, Pod-2, and Pod-3 are identical, running the same app container image, being cloned from the same Pod template.

Although the three Pod replicas are said to be identical, they have unique Pod name and IP address. The Pod object ensures that the application can be individually placed on any worker node of the cluster as a result of the scheduling process.

YAML Example

apiVersion: apps/v1
kind: ReplicaSet
metadata:
  name: frontend
  labels:
    app: guestbook
spec:
  replicas: 3
  selector:
    matchLabels:
      app: guestbook
  template:
    metadata:
      labels:
        app: guestbook
    spec:
      containers:
      - name: php-redis
        image: gcr.io/google_samples/gb-frontend:v3

To create the ReplicaSet:​

kubectl create -f redis-rs.yaml

Assume that one of the Pods is forced to unexpectedly terminate (due to insufficient resources, timeout, its hosting node has crashed, etc.), causing the current state to no longer match the desired state.

The ReplicaSet detects that the current state is no longer matching the desired state and triggers a request for an additional Pod to be created, thus ensuring that the current state matches the desired state.

Deployments

Deployments manage the creation, deletion, and updates of Pods. A Deployment automatically creates a ReplicaSet, which then creates a Pod.

There is no need to manage ReplicaSets and Pods separately, the Deployment will manage them on our behalf.

YAML Example

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  labels:
    app: nginx-deployment
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx-deployment
  template:
    metadata:
      labels:
        app: nginx-deployment
    spec:
      containers:
      - name: nginx
        image: nginx:1.20.2
        ports:
        - containerPort: 80

Apply the manifest:

kubectl apply -f def-deploy.yaml

When you update the Pod template (for example, a container image), Kubernetes performs a rolling update. Each update creates a new ReplicaSet and marks it as a new revision.

Once the rolling update has completed, the Deployment will show both ReplicaSets A and B, where A is scaled to 0 (zero) Pods, and B is scaled to 3 Pods. This is how the Deployment records its prior state configuration settings, as Revisions.

When you update the Pod template (for example, a container image), Kubernetes performs a rolling update. Each update creates a new ReplicaSet and marks it as a new revision.

DaemonSets

A DaemonSet ensures a Pod runs on all (or some) Nodes in the cluster. It’s ideal for running background agents (e.g., log collectors, monitoring tools).

In contrast, the ReplicaSet and Deployment operators by default have no control over the scheduling and placement of multiple Pod replicas on the same Node.

YAML Example

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: fluentd-agent
  labels:
    k8s-app: fluentd-agent
spec:
  selector:
    matchLabels:
      k8s-app: fluentd-agent
  template:
    metadata:
      labels:
        k8s-app: fluentd-agent
    spec:
      containers:
      - name: fluentd
        image: quay.io/fluentd_elasticsearch/fluentd:v4.5.2

Create the DaemonSet:

kubectl create -f fluentd-ds.yaml

Whenever a Node is added to the cluster, a Pod from a given DaemonSet is automatically placed on it. When any one Node crashes or it is removed from the cluster, the respective DaemonSet operated Pods are garbage collected. If a DaemonSet is deleted, all Pod replicas it created are deleted as well.

Authentication, Authorization, and Admission Control

To manage Kubernetes resources, all API requests go through three control stages:

• Authentication: Authenticate a user based on credentials provided as part of API requests.
• Authorization: Authorizes the API requests submitted by the authenticated user.
• Admission Control: Software modules that validate and/or modify user requests.

Authentication

Authentication verifies the identity of a user or service making a request to the API server. Kubernetes doesn’t store user objects but supports various authentication methods:

Different user types:

• Normal users: Managed externally (e.g., client certificates, static token files, OIDC).
• Service accounts: Used by in-cluster processes. Automatically created per namespace and mount credentials into pods. The Service Accounts are tied to a particular Namespace and mount the respective credentials to communicate with the API server as Secrets.

If properly configured, Kubernetes can also support anonymous requests, along with requests from Normal Users and Service Accounts.

Authorization

Authorization determines whether an authenticated user is allowed to perform an action.

More than one module can be configured for one Kubernetes cluster, and each module is checked in sequence. If any authorizer approves or denies a request, then that decision is returned immediately.

Supported Modes

• Node Authorization: Grants kubelet access to node- and pod-related APIs.
• Attribute-Based Access Control (ABAC): Policy-based access using user attributes.
  • To enable ABAC mode, you must start the API server with the –authorization-mode=ABAC option, while specifying the authorization policy with –authorization-policy-file=PolicyFile.json.
• Webhook: Sends authorization requests to an external service.
  • To enable the Webhook authorizer, we need to start the API server with the –authorization-webhook-config-file=SOME_FILENAME option, where SOME_FILENAME is the configuration of the remote authorization service.
• Role-Based Access Control (RBAC) (Recommended).

Example: Role granting pod read access in lfs158 namespace

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  namespace: lfs158
  name: pod-reader
rules:
- apiGroups: [""]
  resources: ["pods"]
  verbs: ["get", "watch", "list"]

In Kubernetes, multiple Roles can be attached to subjects like users, service accounts, etc. In RBAC, you can create two kinds of Roles:

• Role: Grants namespace-scoped permissions.
• ClusterRole: Grants cluster-wide permissions.

Once the role is created, youcan bind it to users with a RoleBinding object. There are two kinds of RoleBindings:

• RoleBinding: Binds a Role or ClusterRole to users/groups/service accounts in a namespace.
• ClusterRoleBinding: Binds a ClusterRole at the cluster scope.

Example: RoleBinding for user bob

apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: pod-read-access
  namespace: lfs158
subjects:
- kind: User
  name: bob
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: pod-reader
  apiGroup: rbac.authorization.k8s.io

Admission Control

Admission controllers validate or modify API requests after authentication and authorization but before persistence.

Controller Types

• Validating: Check request validity.
• Mutating: Modify request objects.

Examples

• LimitRanger: Enforces resource limits.
• ResourceQuota: Enforces resource quotas.
• DefaultStorageClass: Sets default storage class.
• AlwaysPullImages: Forces images to always be pulled.

Enable admission controllers with:

--enable-admission-plugins=NamespaceLifecycle,ResourceQuota,PodSecurity,DefaultStorageClass

Custom controllers can be created as admission webhooks to support dynamic, external validation or mutation.

Accessing Application Pods

Each Pod is assigned a dynamic IP address. If a Pod is restarted, Kubernetes assigns a new IP. If you’re connecting directly to a Pod IP, you’ll lose access when the Pod is replaced.

Example: Accessing Pods by IP

For example, a client accesses Pods using their individual IPs. If one Pod fails, a new Pod is created with a different IP. The client must then detect and update its target IPs, which adds complexity and increases overhead.

To overcome this situation, Kubernetes provides a higher-level abstraction called Service, which logically groups Pods and defines a policy to access them. This grouping is achieved via Labels and Selectors.

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: frontend
  name: frontend
spec:
  replicas: 3
  selector:
    matchLabels:
      app: frontend
    template:
      metadata:
        labels:
          app: frontend
      spec:
        containers:
        - image: frontend-application
        name: frontend-application
        ports:
        - containerPort: 5000

Services

A Kubernetes Service provides a stable network endpoint for a group of Pods. It automatically routes traffic to healthy Pods and load balances requests.

Services use label selectors to identify target Pods.

Create a Service to Expose Pods

First, define a Deployment that runs your application and labels the Pods:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend
spec:
  replicas: 3
  selector:
    matchLabels:
      app: frontend
  template:
    metadata:
      labels:
        app: frontend
    spec:
      containers:
        - name: frontend-application
          image: frontend-application
          ports:
            - containerPort: 5000

Then, expose these Pods using a Service:

apiVersion: v1
kind: Service
metadata:
  name: frontend-svc
spec:
  selector:
    app: frontend
  ports:
    - port: 80
      targetPort: 5000
      protocol: TCP

By default, the Service type is ClusterIP, which exposes the Service only within the cluster.

To apply the Service:

kubectl apply -f frontend-svc.yaml

Or use kubectl expose:

kubectl expose deployment frontend --name=frontend-svc \
  --port=80 --target-port=5000

How Services Group Pods

Services use label selectors to identify groups of Pods. You can define separate Services for each group:

• frontend-svc — targets Pods with app=frontend
• db-svc — targets Pods with app=db

When you create a Service, Kubernetes:

• Assigns it a ClusterIP (accessible only inside the cluster)
• Maps that ClusterIP to a list of Pod IPs and ports (called Endpoints)
• Uses kube-proxy to route traffic based on IP rules

To view the Service and its endpoints:

kubectl get service,endpoints frontend-svc

The client connects to the Service via its ClusterIP. The Service forwards traffic to one of the selected Pods and performs load balancing.

The user/client now connects to a Service via its ClusterIP, which forwards traffic to one of the Pods attached to it. A Service provides load balancing by default while selecting the Pods for traffic forwarding.

Load Balancing and Failover

A Service balances traffic across all healthy Pods. When a Pod is replaced, the Service updates its endpoints list and redirects traffic to the new Pod—no changes needed in client configuration.

Note: Each endpoint includes the Pod’s IP and its target port.

Kube-proxy

In Kubernetes, each node runs kube-proxy, a network proxy that maintains network rules on nodes. It enables communication to your Pods from network sessions inside or outside of your cluster.

Each node runs kube-proxy, which:

• Service Management: kube-proxy watches the Kubernetes API for changes in Service and Endpoint objects, updating the node’s network rules accordingly.
• Traffic Routing: It uses either iptables or IPVS to handle traffic routing. By default, iptables is used, which is simple and well-supported but less efficient than IPVS.

For each new Service, kube-proxy configures iptables rules on each node to capture traffic for the Service’s ClusterIP and forward it to one of the Service’s endpoints. This enables any node to receive external traffic and route it internally based on the iptables rules. When a Service is removed, kube-proxy deletes the corresponding iptables rules from all nodes.

The kube-proxy agent runs on every node, and iptables rules are redundantly populated across nodes. Each iptables instance stores routing rules for the entire cluster, ensuring that Service objects implement distributed load balancing.

Traffic Policies

Kubernetes Services support traffic policies that influence routing decisions:

• Cluster (Default): Routes traffic to all ready endpoints, regardless of their node.
• Local: Routes traffic only to endpoints on the same node as the client. If no local endpoints are available, the traffic is dropped.

You can configure these policies in your Service manifest:

apiVersion: v1
kind: Service
metadata:
  name: frontend-svc
spec:
  selector:
    app: frontend
  ports:
    - protocol: TCP
      port: 80
      targetPort: 5000
  internalTrafficPolicy: Local
  externalTrafficPolicy: Local

Service Discovery

Kubernetes supports two service discovery mechanisms:

• Environment Variables: For each active Service, Kubernetes injects environment variables into new Pods. For example: REDIS_MASTER_SERVICE_PORT.
  • Note: These variables are set only when the Pod starts.
• DNS-Based Discovery: Kubernetes DNS creates names like: my-svc.my-namespace.svc.cluster.local

This allows Services to be discoverable within the cluster.

ServiceType

Kubernetes Services can be exposed in different ways, defined by the type field:

• Is only accessible within the cluster.
• Is accessible from within the cluster and the external world.
• Maps to an entity which resides either inside or outside the cluster.

Access scope is decided by ServiceType property, defined when creating the Service.

ClusterIP (default)

Exposes the Service on an internal IP, making it accessible only within the cluster.

NodePort

Exposes the Service on a static port on each node’s IP. A ClusterIP Service, to which the NodePort Service routes, is automatically created.

LoadBalancer

Exposes the Service externally using a cloud provider’s load balancer. NodePort and ClusterIP Services, to which the external load balancer routes, are automatically created.

Note: Requires cloud provider support.

ExternalIP

Maps a Service to an external IP address. Traffic that is ingressed into the cluster with the ExternalIP (as destination IP) on the Service port, gets routed to one of the Service endpoints

The administrator must configure external routing.

ExternalName

Maps the Service to an external DNS name using a CNAME record. No proxying occurs.

Multi-Port Services

Expose multiple ports in a single Service:

apiVersion: v1
kind: Service
metadata:
  name: my-service
spec:
  selector:
    app: myapp
  type: NodePort
  ports:
    - name: http
      protocol: TCP
      port: 8080
      targetPort: 80
      nodePort: 31080
    - name: https
      protocol: TCP
      port: 8443
      targetPort: 443
      nodePort: 31443

This is a helpful feature when exposing Pods with one container listening on more than one port, or when exposing Pods with multiple containers listening on one or more ports.

Port Forwarding for Local Testing

Use kubectl to forward a local port to a Service for testing:

kubectl port-forward svc/frontend-svc 8080:80

This is useful for debugging applications without exposing the Service externally.

Kubernetes Ingress

Kubernetes Services support internal routing, but defining routing logic per Service leads to duplication and limited flexibility. Ingress decouples routing rules from individual Services and acts as a centralized entry point for external traffic.

Ingress defines HTTP and HTTPS routing rules and acts as a single entry point for external traffic into your cluster. It configures a Layer 7 (application layer) load balancer and supports the following capabilities:

• TLS termination: Offload SSL at the edge.
• Name-based virtual hosting: Route traffic by hostname.
• Fanout routing: Route traffic by URL path.
• Custom routing rules: Use annotations to enable advanced behaviors.
• Load balancing: Distribute traffic across Service backends.

Instead of accessing a Service directly, clients connect to the Ingress endpoint. The Ingress resource defines routing rules that forward requests to the appropriate Service based on hostnames and URL paths.

Note: The Ingress resource itself does not handle traffic. An Ingress Controller—such as NGINX—interprets the rules and manages request forwarding.

Example: Name-Based Virtual Hosting

Use this pattern to route traffic based on the request hostname.

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: virtual-host-ingress
  namespace: default
  annotations:
    nginx.ingress.kubernetes.io/service-upstream: "true"
spec:
  ingressClassName: nginx
  rules:
  - host: blue.example.com
    http:
      paths:
      - path: /
        pathType: ImplementationSpecific
        backend:
          service:
            name: webserver-blue-svc
            port:
              number: 80
  - host: green.example.com
    http:
      paths:
      - path: /
        pathType: ImplementationSpecific
        backend:
          service:
            name: webserver-green-svc
            port:
              number: 80

In this example, requests to blue.example.com and green.example.com are routed to their respective backend Services.

Example: Path-Based Fanout Routing

Use this pattern to route traffic based on the URL path.

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: fan-out-ingress
  namespace: default
  annotations:
    nginx.ingress.kubernetes.io/service-upstream: "true"
spec:
  ingressClassName: nginx
  rules:
  - host: example.com
    http:
      paths:
      - path: /blue
        pathType: ImplementationSpecific
        backend:
          service:
            name: webserver-blue-svc
            port:
              number: 80
      - path: /green
        pathType: ImplementationSpecific
        backend:
          service:
            name: webserver-green-svc
            port:
              number: 80

Requests to example.com/blue and example.com/green are routed to the corresponding Services.

The ingress is fulfilled by an Ingress Controller, which is a reverse proxy responsible for traffic routing based on rules defined in the Ingress resource.

Ingress Controller

The Ingress resource only defines routing rules. It does not route traffic on its own. An Ingress Controller is responsible for fulfilling these rules.

An Ingress Controller:

• Monitors the Kubernetes API for changes to Ingress resources
• Configures the Layer 7 load balancer
• Acts as a reverse proxy for external traffic

Popular Ingress Controllers

• NGINX Ingress Controller
• AWS Load Balancer Controller
• GCE L7 Load Balancer
• Istio Ingress

Note: Each controller may require specific annotations. Always specify the correct ingressClassName and annotations for compatibility.

Deploy an Ingress Resource

After enabling the Ingress Controller, deploy your Ingress resource using:

kubectl create -f virtual-host-ingress.yaml
